| ltem/ Model | DS-430S | DS-550 | DS-500 | DS-750 |
|---|---|---|---|---|
| X-Axis | 400 mm | 500 mm | 500 mm | 700 mm |
| Y-Axis | 300 mm | 400 mm | 400 mm | 500 mm |
| Z-Axis (servo) | 300 mm | 350 mm | 450 mm | 500 mm |
| Max.Workpiece Size (W x D) | 920 x 505 mm | 1100 x 630 mm | 1020 x 710 mm | 1370 x 850 mm |
| Max. Workpiece Weight | 550 kgs | 1350 kgs | 2300 kgs | 3000 kgs |
| Max.Electrode Weight | 120 kgs | 220 kgs | 200 kgs | 250 kgs |
| Distance Between Chuck to Table | 150-450 mm | 135-485 mm | 130-480 mm | 80-580mm |
| Machine Dimensions (W x D x H) | 3124 x 2306 x 2428 mm | 3805 x 2003 x 2578mm | 2426 x 2357 x 2519 mm | 2750 x 2842 x 2668 mm |
| Machine Weight | 1200 kgs | 1950 kgs | 3000 kgs | 4500 kgs |
| Tank Capacity (L) | 380 | 520 | 850 | 1090 |
